OPTICS
LED: 60 x 10W
Multi Color (Quad): RGBW
Optional:
– Full White LED (FW): 2700K,3000K,3500K,4000K,4500K,5000K,5700K,6500K
– Tuneable White LED (TW): 3000K-6500K
Output(10°): 21700lm（Quad）
CRI(FW version): 90,80,70
LED life span: ≥50,000hrs
Beam angle: 10°,15°,25°,30°,60°,20°x65°,etc.
Dimming: linear 0-100%
Optional accessory:
Barndoors (5.05.01.99.0487), snoot ,visor ,yoke ,honeycomb louver(5.03.01.01.2143-B-N0)
MECHANICS
Dimension: 691x557x130mm
Weight: 32 kgs
Lens material : PMMA + anti-UV lens
Mounting: floor, ceiling or wall mounting (adjustable bracket)
ELECTRONICS
Power: 640W
Power factor: >0.9,CCS auto calibrating
Components: integrated driver and power supply
Connector: 8 pin power+DMX integrated cable + IP68 connector
Power: AC 100-277V 50/60Hz
Electronic accessory: plug, leader cable
SOFTWARE
Control: DMX512 /RDM (wireless/DALI/ 0-10V available on request)
DMX channel: FW (1ch) ,TW (2chs) ,RGBW(4chs)
ENVIRONMENT
Ta:-20℃to +45℃
Anti-condensation system: optional
Corrosion resistance: optional for marine environment
Passive cooling: die cast aluminum housing
Compliance: IK08，IP66，Class I
