SOURCE
– 30W LED COB
– CRI >90
– Source life expectancy: > 50.000 h
– n.d.
CONTROL
– DMX
– DALI (on request)
THERMAL MANAGEMENT
– No fan
– High efficiency cooling system
– No heat load from LED engine towards electronic and vice-versa avoiding the risk of failure
due to overheating
– Ta max 40°C
OPTICS
– 70mm High-quality PMMA lens optics
ELECTRICAL
Serie Canova with PSU
– CC LED driver 750 mA / 230 VDC
HOUSING
– Highly resistant body in tecnopolymer / aluminium
– Finishing: Black (RAL on request)
– IP 20
OPTIONS
Serie Canova with PSU
– Track adaptor 230V + binario ONETRACK
CONNECTION
– Power cable: 2m H05RN-F cable live end
COMPLIANCE
– CE
– EN 60598-1; EN 60598-2-1
– SSL Licensing Program
– Manufactured in Italy with Quality System ISO 9001:2015
Datasheet (695.846 KB)
