Beschrijving

Technical data

  • Power consumption: 1200W
  • Power supply voltage: 100 – 245V
  • Voltage frequency: 50/60Hz
  • Diode type: COB 6in1
  • Diode power: 300W
  • Display: Color LCD
  • Number of diodes: 4

Utility data

  • Color: RGBWA + UV
  • Luminous flux: 105 040lm
  • Beam angle (min): 37°
  • Beam angle (max): 37°
  • Dimming:Linear: 0 – 100%
  • Number of DMX channels: 21 (6-32CH)
  • DMX standard: DMX 512
  • Control interface: 4 buttons
  • Operating modes: DMX512, Auto, Sound-controlled, Master / Slave
  • Features: 16-bit dimming, various dimming curves, bulb simulation, DMX Signal regeneration,
  • Electronic protection against overheating

Interfaces

  • AC IN: powerCON
  • DMX IN: XLR – 3 pin
  • DMX OUT: XLR – 3 pin

Physical characteristics

  • Housing made: ABS
  • Cooling: Active, temperature-controlled
  • Height [cm]: 19
  • Width [cm]: 62
  • Depth [cm]: 27
  • Weight [kg]: 9,4
  • Type of packaging: Carton Box
