Spotlight – FN LED 50 NW DMX

Adviesprijs 910,00 excl.btw

Fresnel LED 50W, zoom 12°-76°, White 4000K, DMX, CRI 90

Log in of registreer om uw korting te zien.
Of vraag vrijblijvend een offerte aan.

Demo? Bezoek onze showroom of maak een afspraak voor een demo op locatie.

Wij zijn er voor de professional. Totaal leverancier stage & entertainment

Deskundig advies op maat. Wij denken graag met je mee.

Gespecialiseerd in projectie. Voor elke project een oplossing.

Source:

– 50W LED COB/ARRAY (RGBW)
– Source life expectancy: > 50.000 h
– Note: for Luminous flux and Colour rendering refer to the table at the end of this document

CONTROL

– Protocols: DMX512, RDM (DALI optional)
– Local potentiometer
– Reversible graphics display with standby-shutdown function

OPTICS

– 90mm High-quality glass lens optics
– Note: for Beam angles refer to the table at the end of this document

HOUSING

– Highly resistant body in extruded aluminum
– Finishing: Black
– IP 20

CONNECTION

– Power connector: Chassis PowerCON In/Out
– DMX: XLR 5-pole In/Out panel connectors

COMPLIANCE

– CE – EN 60598-1; EN 60598-2-17
– SSL Licensing Program
– Manufactured in Italy with Quality System ISO 9001:2015

SOFTWARE FUNCTIONS

– ESD: 8 or 16bit extra soft dimming
– 2 selectable dimmer curves
– Adjustable delay in turning on and off
– PWM LED 500Hz-20KHz
– Led boost
– Storage and factory recovery
– Upgradable Firmware via DMX/USB tool

THERMAL MANAGEMENT

– Wide ventilation slots for better LED cooling with selectable fan speed in: “standard”, “silent” and “auto” or DMX regulated
– High efficiency heat pipe cooling system
– No heat load from LED engine towards electronic and vice-versa avoiding the risk of failure due to overheating
– Ta max 40°C

ELECTRICAL

– Power supply: 100-240 V – 50/60 Hz
– Power consumption: 50W
– PF>0.94/230VAC PF>

OPTIONS

– Track adaptor with data bus
